HyperDeck Shuttle HD

Product details of HyperDeck Shuttle HD HDMI Video Inputs 1 HDMI Video Outputs 1 HDMI Audio Inputs 8 channels embedded audio. HDMI Audio Outputs 8 channels embedded audio. Recorder Configuration Via user interface on HDMI Out or Blackmagic HyperDeck Ethernet Protocol. Ethernet 1Gb/s Computer Interface 1 x USB Type-C 3.0 (up to 5Gb/s) for external drive recording, software configuration and updates. Standards SD Video Standards 525i59.94 NTSC, 625i50 PAL HD Video Standards 720p50, 720p59.94, 720p60 1080i50, 1080i59.94, 1080i60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 2K DCI Video Standards 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI Audio Sampling Television standard 24‑bit, 48 kHz sample rate. Video Sampling 4:2:2 YUV Color Precision 10‑bit Color Space REC 601, REC 709. Multi Rate Support Auto detection of SD and HD. Media Media 1 x SD card slot 1 x USB-C 3.0 expansion port for external recording of SD, HD and 2K DCI. Please click here for a summary of compatible media. Media Type UHS-I and UHS-II SD cards. Media Format Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems. Supported Codecs ProRes HQ QuickTime, ProRes 422 QuickTime, ProRes LT QuickTime, ProRes Proxy QuickTime for all formats up to 1080p60. DNxHD 220x, DNxHD 220x MXF, DNxHD 145, DNxHD 145 MXF, DNxHD 45, DNxHD 45 MXF for 720p and 1080p HD formats up to 60fps. H.264 High 4:2:0 8‑bit, H.264 Medium 4:2:0 8‑bit, H.264 Low 4:2:0 8‑bit for all formats up to 1080p60. Control Built in Control Panel 10 buttons for transport and device control plus metal search dial. External Control HDMI start/stop, timecode run. Includes Blackmagic HyperDeck Ethernet Protocol. Supports remote FTP file upload. Teleprompter Multi Rate Support Outputs 23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p defaulting to the highest rate. Supported File Formats Rich text (.rtf) with support for most rich text formatting. Plain text (.txt) Software Software Included Blackmagic OS Blackmagic HyperDeck Setup Internal Software Upgrade Loaded at system start, or via Blackmagic HyperDeck Setup using USB port. Operating Systems Mac 11.1 Big Sur,Mac 12.0 Monterey or later. Windows 10 and 11. Displays LED indicator lights above the media slots. Power Requirements Power Supply 1 x Locking 5.5mm barrel 12V DC In for external power supply or battery use. Power Usage 20 W max. Physical Specifications Environmental Specifications Operating Temperature 0° to 40° C (32°to 104° F) Storage Temperature -20° to 60° C (-4° to 140° F) Relative Humidity 0% to 90% non‑condensing What's Included HyperDeck Shuttle HD 12V universal power supply with international socket adapters Warranty 12 Month Limited Manufacturer's Warranty. Specifications of HyperDeck Shuttle HD BrandBlackmagic DesignSKU2324114688_SGAMZ-13506796009
